- Hydrostatic drive travel system delivers higher transmission efficiency, lower fuel consumption of the whole machine;
- Intelligent deceleration braking system provides higher operating efficiency and reduces braking frequency, reducing braking power consumption;
- Patented energy-saving, high efficiency technology, fixed & variable displacement hydraulics deliver higher efficiency and save more energy;
- Fully upgraded performance contributes to stronger loading capacity and more powerful shovelling capacity of the whole machine;
- Electronically controlled variable intelligent fan saves more energy and lower noise.
886HST
Operating weight:
25,516 kg
Rated power:
240 kW
Rated load capacity:
8,000 kg
Product Features
886HST
886HST
886HST
886HST
Specifications
| Operating weight | 25,516 kg |
| Standard bucket | 4.5 m³ |
| Rated power | 240 kW (322 hp / 326 ps) @ 2,000 rpm |
| Maximum gross power | 285 kW (382 hp / 387 ps) @ 1,700 rpm |
| Rated load capacity | 8,000 kg |
| Hydraulic cycle time | 10.5 s |
| Raise time | 5.8 s |
| Maximum travel speed | 38 km/h |
| Tipping load-full turn | 17,560 kg |
| Bucket breakout force | 240 kN |
| Dump clearance, full height discharge | 3,342 mm |
| Dump reach, full height discharge | 1,275 mm |
| Model | Cummins L9PLUST3 |
| Emissions | EPA Tier 3 / EU Stage III |
| Aspiration | Turbocharged ﹠ air-to-air intercooled |
| Length with bucket down | 9,315 mm |
| Width over tires | 3,055 mm |
| Cab height | 3,580 mm |
| Turning radius, outside of tire | 6,623 mm |
| Bucket capacity | 3.5-8.0 m³ |
| General purpose bucket | 4.5 m³ |
| Light material bucket | 6.0, 7.0, 8.0 m³ |
| Rock bucket | 3.5, 4.0, 4.2 m³ |
| Download Brochure |
※For reference only.
